The ECBD013 smart RCBO circuit breaker integrates electrical protection, remote control, and real-time electrical monitoring into a compact DIN rail device for intelligent power distribution systems. Designed for smart buildings, residential distribution panels, commercial electrical systems, and remote energy management applications, it supports RS485 communication, automatic reclosing, configurable protection parameters, and remote maintenance management.
Supports remote opening, closing, parameter configuration, locking, and unlocking through RS485 communication.
High short-circuit breaking capacity ensures reliable interruption under fault conditions.
Supports adjustable residual current protection with configurable operating thresholds and fast response time.
Provides configurable overvoltage and undervoltage protection with adjustable recovery parameters.
Supports automatic power restoration after outages when operating in automatic mode.
Supports selectable manual and automatic operating modes for different application requirements.
Supports real-time monitoring of voltage, current, and power parameters.
Supports mechanical locking as well as remote locking and unlocking during maintenance operations.
Automatically trips during power-loss conditions when undervoltage protection is enabled.
Standard 35 mm DIN rail installation for switchboards and distribution panels.
| Communication Interface | RS485 |
| Baud Rate | 9600 |
| Communication Address | 1–247 |
| Operating Temperature | -20°C ~ 70°C |
| Ambient Humidity | ≤95% Non-condensing |
| Rated Operating Voltage | AC230V / 400V |
| Number of Poles | 1P / 2P / 3P / 4P |
| Frame Rated Current | 125A |
| Breaking Capacity | Ics 6000A |
| Rated Current Options | 32A / 40A / 50A / 63A / 80A |
| Residual Current Protection | 10–90mA Adjustable |
| Mechanical Life | 20,000 Switching Cycles |
| Electrical Life | 4,000 Switching Cycles |
| Installation Method | 35 × 7.5 mm Standard DIN Rail |
| Operating Mode | Manual / Automatic |
| Remote Functions | Remote Open / Close / Lock / Unlock |
| Residual Current Protection | Adjustable 10–90mA |
| Overvoltage Protection | Adjustable 240–300V |
| Undervoltage Protection | Adjustable 140–190V |
| Automatic Reclosing | Supported |
| Electrical Measurement | Voltage / Current / Power Monitoring |
| Protection Functions | Overvoltage / Undervoltage / Residual Current Protection |
| Model | Configuration |
|---|---|
| ECBD013 | Smart RCBO Circuit Breaker with RS485 |
