The ECSY series Data Acquisition Gateway is designed for centralized collection and management of data from various IoT field devices. It supports multi-vendor water meters, electricity meters, gas meters, heat meters, and other collectors.
The gateway uploads data to a concentrator or an energy data center, enabling multi-terminal access for monitoring, configuration, and management through network communication.
As a critical component of the energy monitoring system, it provides stable and unified data aggregation across diverse end devices.
• Collects operational status and parameters from energy meters, water meters, electricity meters, and other field devices using multiple communication protocols.
• Supports flexible configuration of serial communication parameters including baud rate, parity, data bits, stop bits, and flow control.
• Supports data acquisition and monitoring for up to 176 devices.
• Enables remote maintenance and management through client-side tools.
• Retains historical data for up to 15 days.
• Supports automatic reconnection after power loss or network disconnection.
| CPU | ECSY001A: ARM926EJ, 300 MHz ECSY001B / ECSY001C: Dual-core ARM Cortex-A35, 800 MHz |
| Memory (RAM) | ECSY001A: 64 MB ECSY001B / ECSY001C: 512 MB |
| Flash Storage | ECSY001A: 256 MB ECSY001B / ECSY001C: 8 GB |
| Downlink Interfaces | ECSY001A: 2 × RS485 ECSY001B: 2 × RS485 + 2 × RS485/RS232 ECSY001C: 1 × RS485 + 2 × RS485/RS232 + 5 × M-BUS |
| Uplink Interfaces | ECSY001A: 1 × 10/100 Mbps Ethernet ECSY001B / ECSY001C: 2 × 10/100 Mbps Ethernet |
| Load Capacity | ECSY001A: ≤64 ECSY001B: ≤128 ECSY001C: RS485 ≤96, M-BUS ≤80 |
| Power Supply | AC220V ±10%, 50±1Hz |
| Power Consumption | ≤10W |
| Output Power (if applicable) | DC12V / DC24V |
| Operating Environment | Operating Temperature: –30°C to +60°C Operating Humidity: ≤90% RH (non-condensing) |
| Automatic Reconnection | Supported |
| Local Data Storage | 15 days |
| Dimensions | 370 mm × 290 mm × 100 mm |
| Installation Method | Wall-mount installation |
